Machinery


Our specialised machinery incorporates computer-aided precision engineering. From milling to turning, boring and drilling, McBurney Engineering have the machines to do it all for you. Our professional staff are fully trained in the operation of our equipment, so you can be sure we will deliver a first-rate product to suit your needs.








MAZAK VERTICAL MACHINING CENTRE: AJV-25/405


Travels:

  • X Axis 1000
  • Y Axis 500
  • Z Axis 500

Our Mazak VMC Milling Machine is driven by a fully conversational M32 control which allows for quick programming for any machining. The Mazak is also complemented with our CAD/CAM software in which the machining shape spectrum opens right up with the ability to do 3D machining.











SARO LATHE WITH OSAI CNC CONTROL


Turning Capacities:

  • Turning Dia 450mm
  • Length 3000mm
  • In Gap Dia 800mm
  • Swing Over Bed Dia 730mm

Our Saro Lathe with Osai CNC controller can handle all of your larger machining needs, with the Osai control programs being created by our CAD/CAM software, any profile or shape is achieved with exact precision. The lathe is fitted with a 300mm 3 jaw chuck and a 700mm 4 jaw chuck to ensure chucking of any shapes are easy.











TONGILL CNC LATHE


Turning Capacities:

  • Turning Dia 300mm over crosslide
  • Length 700mm
  • Swing over bed Dia 500mm
  • Turning Dia 500 before crosslide

Our Tongill CNC Lathe is driven by a Fanuc OT control. The turning ability for this machine is vast using the Fanuc OT control combined with the backup of CAD/CAM software, with machine having a 10 inch hydraulic chuck it is perfect for positive clamping of the workpiece with soft jaws. This machine is tooled up with ten turning & boring tools ready to start machining with minimal set up thus quicker and cost effective machining. Using our CAD/CAM software any shape or profile will be achieved with exact precision and speed. Generally used as a jobbing CNC and for smaller production runs.











YAM CNC LATHE


Turning Capacities:

  • Turning Dia 220mm
  • Length 500mm

Our Yam CNC Lathe has a fanuc OT CNC control, this machine is perfect for running production work with a spindle bore of 50mm it allows for bar feeding. Coupled with our CAD/CAM software McBurney Engineering can produce your production work quickly and cost effective.











CK-100 MANUAL LATHE


Turning Capacities:

  • Turning Dia 420mm over crosslide
  • Length 2000mm
  • Swing overbed Dia 660mm

Our manual Lathe which is fitted with digital readouts on all axis, 300mm jaw chuck, 400mm and 500mm 4 jaw chucks is as versatile as it gets for manual machining jobs.











BM-52VE TURRET MILLING MACHINE


Milling Capacities:

  • X Axis 865mm
  • Y Axis 420mm
  • Z Axis 400mm
  • Head rotation left to right 90 degrees
  • Head rotation back & Forth 45 degrees

This Turret Mill is equipped with a digital read out on all axis with programmed in PCD and line drilling cycles, with the machines ability to rotate the turret on 4 axis it makes for very versatile machining.
